汽车运放 IL2903EDT替代NCV2903

Low Power Low Offset Voltage Dua!Comparators

The lL2903 /1L2903E consists of two independentprecision voltage comparators with an offset voltagespecification as low as 2.0 mV max for two comparatorswhich were designed specifically to operate from asingle power supply over a wide range of voltages.Application areas include limit comparators, simpleanalog to digital converters; pulse, square wave andtime delay generators; wide range VCO; MoS clocktimers; multi-vibrators and high voltage digital logicgates.

• Single or Split Supply Operation

• Low Input Bias Current

• Low Input Offset Current

• Input Common Mode Voltage Range to GND

• Low Output Saturation Voltage

• TTL and CMoS Compatible

• IL2903E AEC Q100 Qualified
